Meat Bone Separator

Short Description:

The deboning machine is a type of equipment that deeply processes poultry racks....


Product Detail

Product Tags

The deboning machine is a type of equipment that deeply processes poultry racks. It uses the principle of mechanical sieving to break and filter raw materials, separating minced meat and aggregates. This equipment utilizes the different material properties of poultry meat and bones, and meat has plasticity, while bones do not. Through material propulsion, crushing, pressurization, compression, and other methods, combined with narrow gap separation filters and adjustable bone extraction devices, Mechanical pressure screening is carried out on poultry bones and meat to achieve separation operations. After separation, no bone residue will be found in the meat paste and no meat residue will be left in the skeleton, ensuring the processing effect.

Application

Mainly suitable for the separation and processing of bones and meat from various poultry carcasses or skeletons such as chickens, ducks, geese, fish, and pig throats. The separated meat mince can be used to make sausage, meat cake, Rice-meat dumplings, dumplings and other meat products. The bone residue can be used to extract chondroitin, make soup base, or make bone meal and animal feed.

Features

1.  The device is equipped with a control system, intelligent control, and simpler operation. Can be customized according to customer needs.
2.  Stainless steel components, well selected materials, not easily damaged, and durable.
3.  The separation temperature rise is small, and it has little impact on the flavor and shelf life of the product.
4. The casing has smooth lines, no gaps that can hide dirt or sharp edges that do not harm the operator, making it easy to clean.
Model
Weight
Dimension
Hopper
Volume
Capacity
Power
Voltage
orangemech-100
450kg
1440*630*970mm
20L
500-700kg/h
13/16kw
380V/50HZ
(220V/240V/400V/415V 60HZ 3-Phase)
orangemech-130
800kg
1990*820*1300mm
50L
1000-1500kg/h
13/16kw
orangemech-160
1350kg
2130*890*1400mm
110L
2000-3000kg/h
22/28kw
orangemech-180
1500kg
2420*1200*1500mm
180L
3500-4500kg/h
26/32kw
orangemech-220
2150kg
2750*1450*1750mm
240L
6000-8000kg/h
55kw
orangemech-3000
1650kg
2360*1100*1450mm
120L
3000-4000kg/h
37kw
orangemech-16000
3150kg
2950*1650*1950mm
450L
16000-18000kg/h
90kw
